Graph technology: From SQL to neo4j

Image by Pete Linforth from Pixabay
-----------------------------------------------------------------
| ID | Firstname | Lastname | Date of birth | Notes |
-----------------------------------------------------------------
| 1 | John | Doe | 1984-01-30 | My best buddy |
| 2 | Peter | Piper | 1975-03-13 | Super skilled guy |
| 3 | Jennifer | Jones | 1983-09-15 | |
-----------------------------------------------------------------
-----------------------------------------------------------------
| PersonId | Street | ZIP | City | Country |
-----------------------------------------------------------------
| 1 | Samplestreet 3 | 1234 | Gotham | US |
| 3 | Kings-Avenue 9 | 99123 | Whoville | US |
-----------------------------------------------------------------

Relationships on data level

The flight example

Flight UA703 connects New York JFK and Los Angeles LAX on January 6, 11.36am UTC
SELECT * FROM airports
Results for all-airports-query
SELECT
f.airline,
f.flight_number,
f.tail_number,
f.origin_airport,
f.destination_airport,
f.year,
f.month,
f.day,
f.scheduled_departure
FROM flights f
LEFT JOIN airports a ON f.origin_airport = a.iata_code
WHERE a.city = 'New York'
Results for querying flights departing from New York
SELECT
f.airline,
f.flight_number,
f.tail_number,
f.origin_airport,
f.destination_airport,
f.year,
f.month,
f.day,
f.scheduled_departure
FROM flights f
LEFT JOIN airports a ON f.origin_airport = a.iata_code
LEFT JOIN airports b ON f.destination_airport = b.iata_code
WHERE
a.city = 'New York'
and b.city = 'San Francisco'
SELECT
f.airline,
f.flight_number,
f.origin_airport,
f.destination_airport,
f.year,
f.month,
f.day,
f.scheduled_departure,
f2.airline,
f2.flight_number,
f2.origin_airport,
f2.destination_airport,
f2.year,
f2.month,
f2.day,
f2.scheduled_departure
FROM flights f
LEFT JOIN flights f2 ON f.destination_airport = f2.origin_airport
LEFT JOIN airports a ON f.origin_airport = a.iata_code
LEFT JOIN airports b ON f2.destination_airport = b.iata_code
WHERE
a.city = 'New York'
and b.city = 'San Francisco'
Result for the 2-hop query from New York to San Francisco

So what if a the data model would be designed with relationships in mind, rather than flights or airports?

Hello GraphDB, hello Neo4J

****************************************
| SQL DB | Graph DB *
****************************************
| Database | Graph *
| Table | Does not exist *
| Row | Node *
| Column | Property on node *
| M:M Table | Edge *
| M:M Table Column | Property on edge *
****************************************
  • Airports are created as nodes labeled as Airport with their name shown and colored orange.
  • Flights are created as nodes labeled as Flight with their flight-number shown and colored in blue.
  • Flights and airports are connected with two relationships with dedicated labels for ARRIVING_AT and DEPARTING_FROM
Airports and flights from the previous example turned into a graph

Graphification of the airports and flights

Neo4j sandbox browser

Let’s start loading the airports

LOAD CSV WITH HEADERS FROM 'https://raw.githubusercontent.com/martinhorvath/com.primebird.graphplayground/main/flightnet_airports.csv' AS row
MERGE (airport:Airport {iata_code: row.iata_code})
ON CREATE SET airport.name = row.airport, airport.city = row.city, airport.state = row.state, airport.country = row.country, airport.latitude = toFloat(row.latitude), airport.longitude = toFloat(row.longitude);
LOAD CSV WITH HEADERS FROM 'https://raw.githubusercontent.com/martinhorvath/com.primebird.graphplayground/main/flightnet_airports.csv' AS row
MERGE (airport:Airport {iata_code: row.iata_code})
ON CREATE SET airport.name = row.airport, airport.city = row.city, airport.state = row.state, airport.country = row.country, airport.latitude = toFloat(row.latitude), airport.longitude = toFloat(row.longitude);
MATCH(a:Airport)
return a

Load all flights

LOAD CSV WITH HEADERS FROM 'https://github.com/martinhorvath/com.primebird.graphplayground/raw/main/flightnet_flights.csv' AS row
MERGE (flight:Flight {id: row.id})
ON CREATE SET flight.flight_number = row.flight_number, flight.airline = row.airline, flight.tail_number = row.tail_number, flight.origin_airport = row.origin_airport, flight.destination_airport = row.destination_airport, flight.air_time = row.air_time,flight.departureDate = date(row.year + '-' + row.month + '-' + row.day), flight.departureTime = row.departure_time, flight.departureDate = date(row.year + '-' + row.month + '-' + row.day), flight.arrivalTime = row.arrival_time
MATCH(f:Flight)
return f

Relationships ARRIVING_AT and DEPARTING_FROM

MATCH (a:Airport),(f:Flight)
WHERE a.iata_code = f.origin_airport
CREATE (f)<-[r:DEPARTING_FROM]-(a)
RETURN a,r,f
MATCH (a:Airport),(f:Flight)
WHERE a.iata_code = f.origin_airport
CREATE (f)<-[r:DEPARTING_FROM]-(a)
RETURN a,r,f
MATCH (a:Airport),(f:Flight)
WHERE a.iata_code = f.destination_airport
CREATE (f)-[r:ARRIVING_AT]->(a)
RETURN a,r,f

Experience the power of graph queries

MATCH(a)
WHERE a:Airport
RETURN a;
MATCH(a:Airport)-[r:DEPARTING_FROM]->(f:Flight)
WHERE a.city = "San Francisco"
RETURN a,f;
Flights departing from San Francisco
MATCH(f:Flight)-[r:ARRIVING_AT]->(a:Airport)
WHERE a.city = "New York"
RETURN a,f
Flights arriving at New York
MATCH(a:Airport)-[r:DEPARTING_FROM]->(f:Flight)-[r2:ARRIVING_AT]->(a2:Airport)-[r3:DEPARTING_FROM]->(f2:Flight)-[r4:ARRIVING_AT]->(a3:Airport)
WHERE a.city = "New York" and a3.city = "San Francisco"
RETURN a,f,f2,a2,a3
match p=(a)-[:DEPARTING_FROM|ARRIVING_AT*1..5]->(b)
where a.city='New York' and b.city = 'San Francisco'
return p
match p=shortestPath((a)-[:DEPARTING_FROM|ARRIVING_AT*]->(b))
where a.city='New York' and b.city = 'San Francisco'
return p, length(p)

Manufacturing industry

Utilities and maintenance

Closing word

--

--

--

I'm a consultant working on international projects in the field of geospatial data and customer experience, with a passion for technology and mountaineering.
